Samsung UF-80DX Digital Presenter – High-Zoom, Live XGA Display

The Samsung UF-80DX Digital Presenter redefines live presentation performance with a blend of advanced optics, smooth digital features, and versatile connectivity. With a modernized user interface and compact design, it gives presenters full control over how their documents or objects are displayed in real time. This unit is perfect for education, corporate, or training settings where clarity and flexibility matter.

Key Features & Benefits

• Powerful Zoom Capabilities

  • 14× optical (super wide-angle) zoom for capturing a wide range of object sizes

  • 3× digital zoom to further magnify fine detail

• High-Quality Imaging

  • Utilizes a 1/3" PS-type CCD sensor with 850,000 effective pixels

  • Delivers live XGA (1024×768) output, ensuring sharp color and clarity

• Versatile Connectivity & Control

  • Built-in DVI output for crisp, noise-free digital display

  • USB 2.0/1.1 interface allows real-time image viewing or storage to a PC

  • RS-232C port support for external control systems

• Advanced Image Functions

  • Freeze current image

  • Save and recall up to 8 frames (exclusive to DX model)

  • Image rotation, division (2 × 2 or 3 × 3), color adjustment (brightness, red/blue)

  • Custom user settings: store up to 4 presets for instant recall mid-presentation

• User-Friendly Operation

  • GUI menu interface supports mouse operation

  • Remote controller included for distance operation

  • On-device “INT/EXT” button to quickly switch between internal camera and external input (computer)

• Build & Environmental Specs

  • Operating temperature: +5 °C to +35 °C, humidity 30 %–90 % RH

  • Power: DC 12 V (via included adapter that accepts AC 100–240 V, 50/60 Hz)

  • In-use dimensions: 404 × 488 × 504 mm; Storage: 404 × 206 × 504 mm

  • Weight: approx. 5 kg (11 lbs)

  • Warranty: 3 years

• Optional Accessories

  • Lightbox kit (for transparency or slide work)

  • Extra cables, mounting or carrying hardware
